Zirconium Phosphate (ZrP)

Benefits

l   Dova FR ZrP 309 is high stability with its chemical property and layer structure.

l   It is with relative bigger proportion of surface percentage (total area of the item). high electric density on its surface(charge

numbers on its surface per unit), is a strong type of solid acid.

l   It is It has high stability and intensive mechanical strength (When this material encounters with external force, the unit area can bear the highest capacity).

l   Dova FR ZrP 309 has high crystallinity with its special method.

l   Dova FR ZrP 309 can be classified as a-Zrp, y-zap, t-zap( still under experiment) these three types so far, a-Zrp is available in Dovamat.

Specifications

Dova FR ZrP 309 is can be applied in the below areas:

   Environment Side: Attached to CO2 or gas characterized with acid. It can be produced with: civil construction materials, manned fabricated plates, paper and coatings etc. featuring its absorption with composite multifunctional materials (methanol, ammonia).It is with strong affinity with soda, so that it can produce composite catalyst after its combination with Alcohol, pyridine and some other polar molecules, which can protect our environment. It can produce pesticide with PCBS, PAHS, PCDDS and etc.

    Anti-bacteria side: Work as anti-bacteria material carrying silver. anti-static electricity shoes, conductive electricity shoes. It can work as an additive in plastic, rubber, fiber, coating, paper, adhesives and ceramics and glass to make materials with anti-bacteria. Work as Silver zinc inorganic anti-bacteria agent to dilute composite inorganic anti-bacterial agent, anti-bacterial fiber master. batch, cotton fiber anti-bacteria finishing agent, velvet anti-bacteria and odor finishing agent.

    Modified plastics: 1) In application of modification plastic for low-smoke halogen-free flame retardant, the oxygen index of most common plastics cannot reach 27, while in flame retardant occasions the oxygen index is required to be above 30. Added zirconium phosphate, the index of PP composite material can reach 33, FR level is V-0; For PA6, oxygen index can be up to 38.7, and FR level is V-0. It can suppress the melting and dripping of the matrix, and to be formed a stable carbon layer. 2) The performance function is enhanced to improve the mechanical strength, bending strength, dimensional stability and thermal stability and other physical properties, so that ordinary plastics have special functions that they did not have before, such as: antibacterial, flame retardant, and high temperature resistance.

    Electrochemistry equipment: Solid phase gas sensor; Polymer inorganic proton conductive membrane material; Complete solid phase fuel battery; Electroluminescent material; Molecular Electronics Devices, Nonlinear optical material. Artificial photosynthesis devices6;Film (as a photosensitive combination packing)  Bio Filed: Applied to gene storage as a material including DNA, protein and some other nanometer composite materials formed by bio active molecular.
